Slim IP65 1200Nits 5.95mm Dance Floor LED Screen CE ROHS UL
Approved
Features of Interactive Led Dance Floors:
● Super bright LED lamp bead gold line package and A grade raw
material plastic package.
● High-end LED screen special waterproof silica gel.
● PCB adopts exclusive line design.
● The signal line and power line adopt the standard design of the
standard.
● LED lamp bead bracket pure copper bracket, red light 12MIL, blue
green 13MIL.
● The PC cover is made of anti-slip and the bearing weight is above
2T.
● Realization of human-computer interaction experience
(abbreviation: interactive effect.)
Application of LED display:
Wide applied in stadiums, advertisement, banks, securities
exchange, stations, shoping malls
Postal officees, schools, monitoring, restaurants, entertainment,
enterprises etc...
Technical pareameters:
| Item | Parameter | Unit |
| Pixel pitch | 5.95 | mm |
| Brightness | 1000-1200 | nits |
| Panel size | 1000x500x75 | mm |
| Panel material | aluminum | |
| Panel weight | 13.6 | kg/unit |
| Pixel density | 3-in-1 SMD2121 | |
| Module size | 250x250 | mm |
| Panel resolution | 168x84 | pixel/panel |
| Pixel density | 28224 | pixel/sq.m |
| Refresh reate | ≥3840 | Hz |
| Gray scale | 65536 | degree |
| Color temperature | 3200-9300 adjustable | K |
| Driving method | 1/7 scan | scanning |
| Power supply | JN backup | 2x(5v-30A) |
| Viewing angle(H/V) | 150/120 | degree |
| Protection | IP65 | level |
| Power(max/ave) | 1200/640 | W |
| Input voltage | 110-240VAC | V |
| Working temp. | ﹣20 ～﹢50 | ℃ |
| Working humidity | 10％ ～ 90％ | |
| Input signal | AV,S-Video,VGA,DVI,HDMI,SDI,DP | |
| Control distance | 100m with HSYV; 10KG with fiber | |
| Certificate | CCC, TUV-CE, ETL | |
| Frame rate | 50 & 60 | Hz |
| Safety feature | GB443/EN60950 | |
| Evenness(brightness & color) | ≥97% | |
| Driving IC | MBI5152 |
Why choose us ?
1. more than 10 years experience in led display industry, we have
most talented engineers to design best products for our clients;
2. "Customer first" is our belief. We promise to offer best
products with good service for our clients;
3. Top quality machines to make top quality products;
4. Strict processing procedures makes perfect product. Every
production procedure, we have QC to check the quality;
5. Most competitive price make our led displays are afordable;
6. Normally 2 years warranty, even we can offer 3 years warranty if
our clients need;
7. For key business partners, we can offer financial credit;
FQA:
- What is the payment method?
- We support a variety of payment methods, the most common is the TT;
- How about your production ability?
- We have 10 production lines with all series of automatic production
machines. Monthly production ability: 200,000pcs of led modules and
4,000sqm of assembled led displays;
- What's the controlling system?
- Our standard controlling system for this model is Linsn/ Novastar.
Also support other controlling system,like HD,Xixun,TF, Colorlight,
etc;
- Are you manufacturer or trading company?
- We are manufacturer with professional marketing and service team;
- Besides this product, may I have other options?
- Yes, my dear friend. Many thanks for finish the details of this
product. If it is not what you're looking for, you can also choose
other items. we have HD indoor led display, full color for outdoor
and indoor; Different cabinet, Steel Cabinet, Aluminum Cabinet, Die
Cast Aluminum Cabinet, etc; The pixel pitch is from 1.5mm to 20mm.
We also have LED advertising player and kinds of video processor;
- Can it play HD video?
- Yes, it can realize HD video function with Linsn/nova controlling
system;
