1. Wide view angle
With 120/120degree view angle ,bring a wonderful image
2. Light, thin and intensive design offers more space to be
creative
3. Information source can be camera, video, VCD, DVD, LD, TV and so
on; Clear picture without flicker and distortion
4. Black LED and light absorbing mask patent increase the display
effect
5. High definition guarantee excellent performance
6. First-class LED chip: Supplied by Cree & other high strictly
selected LED chip to ensure the long lift-time and high brightness
of our LED display screen system
7.Clear vivid image quality even in direct, full-on sunlight to
ensure you attracts more audience to get short ROIof your LED
display screen's investment.
Application Case:
Mainly used to do outdoor advertisement just like TV, in addition,
it also can be used to play the Events, Showing, Cinema, Sports,
etc.
Our service:
1. Enquiry response time: within 12hrs.
2. OEM&ODM: design and produce your customized requirements.
3. Provide distributors customized design and models we already
have.
4. Protect your sales area, design idea and all your private
information.
5. Top quality + reasonable price + patient after-sales service.
6. Brilliant Opto can also offer you LED stage display, LED outdoor
video wall, wedding LED display, stage LED electronic screen and
LED large screen full color display.
Trade Terms:
1. Package: anti-shaking wooden package, air flight case or carton
package.
2. Payment: T/T, 30% deposit before production, 70% balance to be
paid before delivery.
3. Free to support and train your operator.
4. Shipping port: Shenzhen, Mainland China.
5. Warranty time: 2 years
6. Delivery time: 7-15 working days.
| Features |
| Pixel pitch: | 4mm |
| Density: | 62500 dots/㎡ |
| Lamp origin: | R/G/B=Kinglight |
| Colors: | 1R1G1B |
| Led specs: | SMD2121 |
| Module resolution: | W64×H32 |
| Best viewing distance: | ≥4m |
| Best viewing angle: | H120,V120 |
| Environment temperature: | (-30ºC ~ +90ºC) |
| Working temperature: | (-20ºC ~ +50ºC) |
| RH: | 25~95% |
| Module weight: | About 225g. |
| Average power consumption: | 485W/㎡ |
| Largest power consumption: | 686W/㎡ |
| Scan mode: | 1/16S |
| rame frequency: | ≥60 frame/s |
| Refresh rate: | ≥960 Hz/s |
| Grey scale levels/Color processing: | 4096levels,Process 16.7M colors |
| Full white brightness: | ≥1000cd/㎡ |
Some Cabinets and Packing:
Project Cases:
FAQ:
1. Are you the manufacturer or trading company?
We are professional manufacturer of Led outdoor, Led indoor
display, rental display, stadium screen, stage screen and
advertising screen.
2. What kind of package can you choose?
Wooden case or flight case,And if you choose flight case,there will
be extra charge.
3. What is LED?
LED is the abbreviation leds (LIGHT EMITTING DIODE), it's emit
visible wave lengths led
in the LED display industry
4. What is a pixel and pixel pitch?
The pixel is the smallest unit of lightemitting,consists of
red,green and blue colors.The
same as ordinary computer monitors.
Pixel pitch refers to the center of the distance between two
adjacent pixels.
5. What is the LED display module?
The base unit determined by circuit and installation structure,has
the display function,
can simple assembling.
6.What is 3 in 1? What is its advantages and disadvantages?
The RGB color of LED chips encapsulation SMT light vertical tied
together according
to certain spacing.
The advantages are: simple production, display effect is good.
The disadvantage is spectral color separation difficult, high cost.
