128x128mm P2 Indoor Led Display , SMD1515 Led Tv Advertising
Displays
Product Features
1. LEDs. we select super led tips with high brightness, broad
viewing angle(H140degree, V140degree), all the LEDs are ageing for
72 hours before assembly,
when in modules, also aging for 72 hours, after assembly into a
screen, still aging 72 hours. so the final LEDs are aging at least
for 216 hours, up to 9 days.
2. Modules. we use SMD1921 3in1 pixel configuration to realise high
brightness. you may find some lower price suppliers but also same
brightness. if you note, maybe they use is not Nation star LEDs
lamp, in this case, can cut down much cost but also cut down the
life of the display. why? because to reach the same brightness and
better waterproof, it is big square lamps from nation star unique
design can do it. and our modules case is PVC, which is more
durable and have a stronger ability in bask, anti-ultraviolet and
Difficult to deformation than Plastic ones.
3. Cabinets. they are used in galvanized steel, or super
lightweight Magnesium alumnium die casting cabinets, anti-salt,
anticorrosive and waterproof.
4. Screen. use state-of-the-art LED drive IC-ICN2038S, brightness
can up to 8000cd/m2, live color video and vivid image with 256 grey
level. for outdoor led displays, all of them are IP65 and designed
to withstand harsh environmental conditions, such as sun glare,
heat, cold, and humidity. you can see more details in the
quotation.
SPECIFICATION OF X2 Indoor Advertising LED Display Screen
| Model | X2 |
| Pixel pitch(mm) | 2 |
| Configuration | SMD 1515 |
| Module dimension(mm) | 128x128 |
| Module weight(kg) | 0.2 |
| Cabinet dimension(mm) | 512x512x75 |
| Pixel density(dots/㎡) | 250000 |
| Flatness error(mm) | ≤0.1 |
| Viewing angle | 140°/140°(Horizontal/Vertical) |
| Brightness(cd/㎡) | 1000 |
| Color temperature(K) | 5000~9500 (Adjustable) |
| Contrast | 5500:1 |
| Repetition frequency | 50/60Hz |
| Refresh frequency(Hz) | ≥2880 |
| Gray scale | 16bit |
| Ave. power(W/㎡) | 290 |
| Max power(W/㎡) | 560 |
| Working temp./humidity | -10~40℃/10%~80%RH |
| Storing temp./humidity | -20~60℃/10%~85%RH |
| Cabinet material | Iron/Aluminum |
| Maintenance | Front/Rear maintenance |
| Protection | IP40/IP43 |
| Driving mode | Constant current driver |
| Scanning | 1/30 S |
| Power requirements | AC90~264V, 47~63Hz |
| Life time(hrs) | 100,000 |
Competitive Advantages:
1. Good quality;
2. Good price;
3. Good 24hours service;
4. Promote delivery;
5. Energy-saving;
6. Small order accepted.
Our service
1) Reply your inquiry in 24 working hours.
2) Experienced staffs answer all your query in fluent
English,Spanish,French,German etc
3) Customized design is available,OEM & ODM are welcomed.
4) Exclusive and unique solution can be provided to our customer by
our well-trained and professional engineers and staffs.
5) Special discount and protection of sales area provided to our
distributor.
6) Warmly welcome your visit in our company if available.
7 ) Guidance service: We can guide on line if customers have
questions about the installation and usage.
For large project, we provide your engineer a week free training,
or if customer could bear the relevant cost, our engineer can go to
customer's country for on-site guidance.
8) Warranty period: 2 years after shipment.
